| Specifications | ||||||||||||
| MODEL NO. | BEARING | RATED | START | OPERATING | RATED | RATED | SPEED | AIR | STATIC | NOISE | ||
| VOLTAGE | VOLTAGE | VOLTAGE | CURRENT | POWER | FLOW | PRESSURE | ||||||
| VDC | V | V | A | W | R.P.M | CFM | M3/MIN | mmAq | INH2O | db(A) | ||
| JD401005HBP | Ball | 5 | 3.5 | 4.25~5.75 | 0.23 | 1.15 | 7000 | 8.40 | 0.24 | 3.12 | 0.12 | 31 |
| JD401005MBP | Ball | 5 | 3.5 | 4.25~5.75 | 0.16 | 080 | 6000 | 7.18 | 0.20 | 2.29 | 0.09 | 27 |
| JD401005LBP | Ball | 5 | 3.5 | 4.25~5.75 | 0.12 | 060 | 5000 | 6.48 | 0.18 | 1.87 | 0.07 | 25 |
| JD401012HBP | Ball | 12 | 6 | 10.2~13.8 | 0.12 | 1.44 | 7000 | 8.40 | 0.24 | 3.12 | 0.12 | 31 |
| JD401012MBP | Ball | 12 | 6 | 10.2~13.8 | 0.10 | 1.2 0 | 6000 | 7.18 | 0.20 | 2.29 | 0.09 | 27 |
| JD401012LBP | Ball | 12 | 6 | 10.2~13.8 | 0.08 | 0.96 | 5000 | 6.48 | 0.18 | 1.87 | 0.07 | 25 |
| JD401024HBP | Ball | 24 | 12 | 20.4~27.6 | 0.09 | 2.16 | 7000 | 8.40 | 0.24 | 3.12 | 0.12 | 31 |
